DS90CR286AMTDX - Texas Instruments

Manufacturer Part Number

DS90CR286AMTDX

Manufacturer

Texas Instruments

Introduction

The DS90CR286AMTDX is a high-performance, low-power LVDS receiver designed for high-speed digital video applications.

Product Features and Performance

High-speed data transmission up to 400Mbps

Low power consumption

Integrated termination resistors

Wide common-mode input voltage range

Supports 3V to 3.6V supply voltage

Differential input sensitivity of 100mV

Propagation delay of 2ns (typical)

Integrated fail-safe circuitry

Product Advantages

Enables high-speed, low-power digital video transmission

Simplifies system design with integrated termination and fail-safe features

Suitable for a variety of applications, including automotive, display, and machine vision systems

Key Technical Parameters

Data rate: Up to 400Mbps

Supply voltage: 3V to 3.6V

Input sensitivity: 100mV (differential)

Propagation delay: 2ns (typical)

Package: 56-TSSOP

Quality and Safety Features

Robust design for reliable operation

Complies with automotive and industrial standards

ESD protection up to 8kV

Compatibility

Compatible with LVDS standards

Suitable for use in a variety of digital video applications

Application Areas

Automotive infotainment systems

Digital displays and monitors

Machine vision and imaging systems

Printers and copiers

Product Lifecycle

Currently in active production

Replacement or upgrade options available if needed

Key Reasons to Choose This Product

High-speed, low-power data transmission for efficient digital video applications

Integrated features like termination and fail-safe circuitry simplify system design

Robust design and compliance with industry standards ensure reliability and safety

Versatile compatibility with a wide range of digital video applications
