CSD97376Q4M - Texas Instruments

Manufacturer Part Number

CSD97376Q4M

Manufacturer

Texas Instruments

Introduction

The CSD97376Q4M is a high-performance, half-bridge driver integrated circuit (IC) from Texas Instruments, designed for use in synchronous buck converter applications.

Product Features and Performance

Operates at 4.5V to 5.5V supply voltage

Supports up to 24V load voltage

Delivers up to 20A output current per channel

Capable of handling up to 45A peak output current

Includes bootstrap circuit for driving high-side MOSFET

Provides shoot-through and UVLO (undervoltage lockout) fault protection

Optimized for high-frequency, high-efficiency switching

Product Advantages

Compact 8-pin VSON (3.5x4.5) package

Supports wide range of operating temperatures (-40°C to 150°C)

Efficient power delivery with high-performance NexFET technology

Reliable fault protection features

Suitable for a variety of synchronous buck converter applications

Key Technical Parameters

Package: 8-PowerVFDFN

Mounting Type: Surface Mount

Operating Temperature: -40°C to 150°C

Series: NexFET

Packaging: Tape & Reel (TR)

Bootstrap Circuit

Half-Bridge Output Configuration

PWM Interface

Quality and Safety Features

RoHS3 compliant

Reliable fault protection mechanisms (shoot-through, UVLO)

Compatibility

Suitable for use in synchronous buck converter applications

Application Areas

Synchronous Buck Converters

Inductive Load Applications

Product Lifecycle

The CSD97376Q4M is an active product, and Texas Instruments provides ongoing support and availability.

Several Key Reasons to Choose This Product

High-performance half-bridge driver with efficient NexFET technology

Capable of handling high output currents up to 45A peak

Compact and thermally-efficient 8-pin VSON package

Reliable fault protection features for safe and reliable operation

Wide operating temperature range (-40°C to 150°C) for versatile applications

Supports a wide range of load voltages from 4.5V to 24V

Optimized for high-frequency, high-efficiency synchronous buck converter designs
