Manufacturer Part Number
CD74HC4049M96
Manufacturer
texas-instruments
Introduction
The CD74HC4049M96 is part of the 74HC series, functioning as a high-speed CMOS logic buffer, inverting type, with six elements and one bit per element. It is designed for efficient signal inversion with high drive capability and is packaged in Tape & Reel (TR) for automated assembly processes.
Product Features and Performance
Integrated six inverting buffers
High current output of 5.2mA, both high and low
Wide operating voltage range from 2V to 6V
Suitable for operating in extreme temperatures ranging from -55°C to 125°C
Surface Mount 16-SOIC packaging for compact integration
Push-Pull output type for better signal integrity
Part of the highly reliable 74HC logic family
Product Advantages
High noise immunity
Lower power consumption compared to other logic families
Broad compatibility with various microcontrollers and digital systems
Robust performance in harsh temperature environments
Enables high-speed operation thanks to CMOS technology
Key Technical Parameters
Logic Type: Buffer, Inverting
Number of Elements: 6
Number of Bits per Element: 1
Current Output High, Low: 5.2mA
Voltage Supply: 2V ~ 6V
Operating Temperature: -55°C ~ 125°C
Package / Case: 16-SOIC
Quality and Safety Features
Manufactured by texas-instruments, a leader in semiconductor technology
Compliant with industry standards for safety and quality
Compatibility
Versatile logic voltage levels for easy integration into digital systems
SOIC package compatible with standard PCB layouts
Application Areas
Signal processing
Logic inversion
Digital electronics projects
Automation systems
Telecommunications
Product Lifecycle
Status: Active
With ongoing production, there is no immediate concern for discontinuation. Availability of replacements or upgrades will follow texas-instruments' product lifecycle guidelines.
Several Key Reasons to Choose This Product
High reliability and robustness for critical applications
Broad operating temperature range suitable for demanding environments
High compatibility with a wide range of digital systems
Efficient power consumption supporting battery-powered applications
Proven texas-instruments quality and support for product integration and troubleshooting
