CD4044BNSR - Texas Instruments

Manufacturer Part Number

CD4044BNSR

Manufacturer

Texas Instruments

Introduction

The CD4044BNSR is a high-quality Logic Latch from the 4000B series, designed by Texas Instruments for a wide range of storage applications. It features Tri-State outputs and is optimized for use in digital systems where low power consumption and high reliability are critical.

Product Features and Performance

High-speed S-R Latch logic type

Offers four independent circuits

Tri-State outputs to enable shared bus lines

Wide operating voltage range from 3V to 18V

Fast propagation delay time of 50ns

Capable of driving 6.8mA loads both high and low

Functions reliably across a wide temperature range (-55°C to 125°C)

Product Advantages

Versatile voltage range for diverse applications

Enhanced data storage integrity with Tri-State output control

Low power consumption suitable for battery-operated devices

High integration with four independent S-R latches reduces component count

Key Technical Parameters

Logic Type: S-R Latch

Circuit: 1:1

Output Type: Tri-State

Voltage Supply: 3V ~ 18V

Independent Circuits: 4

Delay Time Propagation: 50ns

Current Output High, Low: 6.8mA

Operating Temperature: -55°C ~ 125°C

Mounting Type: Surface Mount

Package / Case: 16-SOIC

Supplier Device Package: 16-SO

Quality and Safety Features

Designed and manufactured by Texas Instruments, a leader in semiconductor solutions, ensuring high product reliability and performance consistency. Meets industrial safety and quality standards.

Compatibility

The CD4044BNSR’s standard 16-SOIC package and surface-mount design ensure compatibility with a wide range of PCB designs and equipment.

Application Areas

Suitable for digital systems in telecommunications, computing, consumer electronics, automotive systems, and more. Ideal for applications requiring data storage, signal gating, and control logic.

Product Lifecycle

Currently active, indicating ongoing manufacturer support, availability, and no immediate risk of discontinuation. Texas Instruments typically provides advance notification if a product is nearing the end of its lifecycle, alongside options for replacement or upgrades.

Several Key Reasons to Choose This Product

Reliable performance in extreme temperatures

Low power operation enhances battery life

Flexible for use in a broad array of digital applications

Texas Instruments' legacy of quality and support

Ease of integration into existing and new designs with surface-mount packaging

Suitable for applications demanding high data integrity and system reliability
