CD4013BNSR - Texas Instruments

Manufacturer Part Number

CD4013BNSR

Manufacturer

Texas Instruments

Introduction

The CD4013BNSR is a dual D-type flip-flop logic device designed by Texas Instruments, part of the 4000B series. It is primarily used in applications requiring a stable logic state that can be controlled by preset or reset conditions.

Product Features and Performance

Dual D-Type Flip-Flop configuration

Positive Edge Trigger Type

Complementary Output Type

Maximum Clock Frequency of 24 MHz

Maximum Propagation Delay of 90ns at 15V, 50pF

Capable of operating within a voltage supply range of 3V to 18V

Low quiescent current of 4 µA

Input Capacitance of 5 pF

Product Advantages

High noise immunity

Stable logic states controlled via set (preset) and reset inputs

Low power consumption due to minimal quiescent current

Key Technical Parameters

Number of Elements: 2

Number of Bits per Element: 1

Clock Frequency: 24 MHz

Propagation Delay: 90ns @ 15V, 50pF

Output Current: High, Low 6.8mA

Voltage Supply Range: 3V ~ 18V

Quiescent Current: 4 µA

Input Capacitance: 5 pF

Operating Temperature Range: -55°C ~ 125°C

Quality and Safety Features

Robust operating temperature range of -55°C to 125°C ensures reliability under extreme conditions

Compatibility

Mounting Type: Surface Mount

Package: 14-SOIC (0.209", 5.30mm Width)

Application Areas

Timers

Shift Registers

Automotive systems

Data storage applications

Industrial electronics

Product Lifecycle

The CD4013BNSR is currently active and widely available. It is not nearing discontinuation, and replacements or upgrades are available if necessary.

Several Key Reasons to Choose This Product

High reliability with extensive temperature range suitability

Low power operation enhancing device longevity and energy efficiency

Flexible voltage supply range facilitating integration into various circuit designs

Dual flip-flop configuration offering versatility in logic circuit applications

Broad compatibility with surface mount technology for simplified PCB design
