ATL431AQDBZR - Texas Instruments

Manufacturer Part Number

ATL431AQDBZR

Manufacturer

Texas Instruments

Introduction

Adjustable shunt voltage reference for power management applications

Product Features and Performance

Adjustable output voltage (2.5V to 36V)

Maximum current output of 100 mA

High precision with a tolerance of ±1%

Stable temperature coefficient at 82ppm/°C

Surface mount package for compact circuitry

Product Advantages

Adjustable for a wide range of applications

Precision regulation ensuring stable voltage

Low temperature dependency enhances reliability

Key Technical Parameters

Reference Type: Shunt

Output Type: Adjustable

Voltage - Output (Min/Fixed): 2.5V

Voltage - Output (Max): 36V

Current - Output: 100 mA

Tolerance: ±1%

Temperature Coefficient: 82ppm/°C

Current - Cathode: 35 µA

Operating Temperature: -40°C ~ 125°C

Quality and Safety Features

Stable performance over wide temperature range

Robust surface mount package

Compatibility

Compatible with a wide range of circuits requiring voltage reference

Application Areas

Power supplies

Battery management

Data acquisition systems

Consumer electronics

Product Lifecycle

Active status, not nearing discontinuation

Availability of replacements or upgrades not specified

Several Key Reasons to Choose This Product

High output current capability suitable for demanding applications

Precision output voltage tolerance enables reliable performance

Wide output voltage range accommodates diverse use-cases

Low temperature coefficient ensures minimal drift over temperature

Scalable to different power levels based on application requirements

Industry-standard SOT-23-3 packaging for easy integration into existing designs
