Manufacturer Part Number
ADS4225IRGCR
Manufacturer
Texas Instruments
Introduction
High-speed, dual-channel, 12-bit Analog to Digital Converter
Product Features and Performance
12-bit resolution
Dual channel ADC
125 MSPS sampling rate
Differential input type
Internal voltage reference
Simultaneous sampling
LVDS and parallel data interface
Product Advantages
High-speed performance for demanding applications
Simultaneous sampling for accurate dual-channel measurements
Low voltage operation reduces power consumption
Key Technical Parameters
Number of Bits: 12
Sampling Rate: 125M samples per second
Number of Inputs: 2
Input Type: Differential
Data Interface: LVDS, Parallel
Number of A/D Converters: 2
Architecture: Pipelined
Voltage Supply Analog: 1.7V to 1.9V
Voltage Supply Digital: 1.7V to 1.9V
Operating Temperature: -40°C to 85°C
Quality and Safety Features
Extended temperature range for reliability in harsh environments
Robust VFQFN package
Compatibility
Compatible with various microcontrollers and DSPs through LVDS and parallel interfaces
Application Areas
High-speed signal processing
Medical imaging
Data acquisition systems
Communications
Product Lifecycle
Active product status
Supplied in Tape and Reel for efficient assembly
Several Key Reasons to Choose This Product
High sampling rate ideal for real-time applications
Integrated dual ADCs reduce component count
Precision data conversion improves signal quality
Designed by Texas Instruments, a leader in ADC technology
Supports advanced digital processing systems with LVDS and parallel outputs
Energy-efficient operation for portable and battery-powered devices
Robust operation in extended industrial temperature ranges
