ADS1298IPAGR - Texas Instruments

Manufacturer Part Number

ADS1298IPAGR

Manufacturer

Texas Instruments

Introduction

The ADS1298IPAGR is a high-performance, multichannel analog front-end (AFE) designed for medical electrocardiogram (ECG) applications and biopotential measurements.

Product Features and Performance

24-bit resolution offers high precision measurements.

8 channels support multiple data capture simultaneously.

Low power consumption of 14.1 mW improves battery life for portable devices.

Wide analog supply voltage range (2.7V ~ 5.5V) provides flexibility in system design.

Digital supply voltage range (1.65V ~ 3.6V) accommodates various microcontrollers and digital interfaces.

Surface mount 64-TQFP package aids in compact design implementation.

Product Advantages

High resolution and multi-channel capabilities enable detailed and simultaneous capturing of complex biopotential signals.

Low power requirement enhances the portability of medical devices.

Flexibility in supply voltage ranges allows compatibility with a wide range of system architectures.

The compact footprint enables the design of dense and miniaturized electronic boards.

Key Technical Parameters

Number of Bits: 24

Number of Channels: 8

Power (Watts): 14.1 mW

Voltage Supply, Analog: 2.7V ~ 5.5V

Voltage Supply, Digital: 1.65V ~ 3.6V

Mounting Type: Surface Mount

Package / Case: 64-TQFP

Quality and Safety Features

Designed to meet stringent medical application requirements.

Texas Instruments’ quality manufacturing ensures high reliability and performance.

Compatibility

Compatible with various microcontrollers and digital systems due to its digital supply voltage range.

The surface mount package allows for easy integration into PCB designs.

Application Areas

Medical electrocardiogram (ECG) devices.

Biopotential measurement equipment.

Portable and battery-operated medical devices.

Product Lifecycle

Currently in active production.

No current indication of nearing discontinuation, ensuring long-term availability.

Replacement and upgrade options are typically provided by Texas Instruments for futureproof integration.

Several Key Reasons to Choose This Product

High-precision, 24-bit resolution ideal for sensitive medical applications.

Multi-channel functionality enables comprehensive biopotential analyses.

Low power consumption supports the development of portable, battery-powered devices.

Versatile supply voltage ranges offer integration flexibility.

Compact package design facilitates miniaturized electronic board designs.

Texas Instruments' reputation for quality and reliability ensures confidence in product performance and lifecycle management.
