Manufacturer Part Number
ADC101S021CIMF
Manufacturer
Texas Instruments
Introduction
The ADC101S021CIMF is a 10-bit Analog to Digital Converter from Texas Instruments, designed primarily for data acquisition applications that require a sampling rate of 200k per second.
Product Features and Performance
10-bit resolution
Single-channel input
Single Ended input type
Implements SAR architecture
Data interface includes SPI and DSP
Operates within an analog supply voltage range of 2.7V to 5.25V and a digital supply voltage range of 2.7V to 5.25V
Supports a temperature range from -40°C to 85°C
Product Advantages
Compact size provided by SOT-23-6 packaging
Simple interfacing with digital systems thanks to SPI and DSP supported data interface
Key Technical Parameters
Number of Bits: 10
Sampling Rate (Per Second): 200k
Number of Inputs: 1
Input Type: Single Ended
Voltage - Supply, Analog: 2.7V ~ 5.25V
Voltage - Supply, Digital: 2.7V ~ 5.25V
Operating Temperature: -40°C ~ 85°C
Quality and Safety Features
Stable performance within a wide temperature range of -40°C to 85°C
Compatibility
Compatible with microcontrollers and systems supporting SPI and DSP interfaces.
Application Areas
Used in various electronic data acquisition systems where space and accurate rapid-data measurements are critical.
Product Lifecycle
The product status is marked 'Obsolete'. Hence, it may be nearing the end of its production life, and users should verify availability or seek alternative solutions or upgrades if required.
Several Key Reasons to Choose This Product
High-speed operation suitable for rapid data acquisition needs
Simple digital interfaces with SPI and DSP support for flexible system integration
Compact form factor aiding in space-saving designs
Wide operating temperature range ensuring reliability in varied environmental conditions
Direct power support from commonly used supply voltages, simplifying system power design considerations
