74LVC1G126DCKRG4 - Texas Instruments

Manufacturer Part Number

74LVC1G126DCKRG4

Manufacturer

Texas Instruments

Introduction

The 74LVC1G126DCKRG4 is a high-speed CMOS buffer from Texas Instruments, specifically designed for use in controlling line capacitance and driving highly capacitive or relatively low-impedance loads. As part of the 74LVC series, this device is engineered to provide optimal performance in logic buffering and driving applications.

Product Features and Performance

Single buffer/line driver with 3-state output

Operates from a wide voltage range (1.65V to 5.5V)

High drive strength of 32mA at both high and low levels

Low power consumption

Enhanced ESD protection

Product Advantages

Flexible power supply compatibility

Capable of driving heavy loads

Suitable for high-speed applications

Minimal power dissipation

Key Technical Parameters

Logic Type: Buffer, Non-Inverting

Number of Elements: 1

Number of Bits per Element: 1

Output Type: 3-State

Current Output High, Low: 32mA

Voltage Supply: 1.65V ~ 5.5V

Operating Temperature: -40°C ~ 125°C

Quality and Safety Features

Over-temperature shutdown mechanism

High Electrostatic Discharge (ESD) protection level

Compatibility

Compatible with a wide range of logic families due to its broad supply voltage range

Application Areas

High-speed signal buffering

Data transmission

Signal conditioning

Logic level shifting between different operating voltages

Product Lifecycle

Discontinued at Digi-Key, suggesting it is nearing end-of-life, potentially with limited availability. Customers should consult Texas Instruments for replacements or upgrades.

Several Key Reasons to Choose This Product

Texas Instruments' reputation for quality and reliability

Wide operating voltage range makes it suitable for various applications

High output current capability enables driving of capacitive loads

Low power consumption enhances system efficiency

3-State outputs facilitate bus interfacing
